8060SRC23.10
A03030018/02 FLYWHEEL HOUSING SAE 3 - with PICK-UP seat
| Item | Part number | Description |
|---|---|---|
| 1 | 8014731 | FUEL LINE |
| 2 | 4858608 | SEAL GASKET dia.14x19,5x1,5 |
| 3 | 8014732 | FUEL LINE |
| 4 | 4659217 | DOWEL |
| 5 | 4659218 | CLIP |
| 6 | 4659219 | PLATE |
| 7 | 16602324 | HEXAGON BOLT M5X25 MM |
| 8 | 17494634 | SPRING WASHER Ø5,1X9,2 MM |
