8061C05.05
A01050017/02 OIL SUMP - max longitudinal inclination 45°
| Item | Part number | Description |
|---|---|---|
| 1 | 8112374 | RETAINER |
| 2 | 4852561 | FLAT ENGINE GASKET |
| 3 | 8112401 | SUCTION STRAINER |
| 4 | 17157021 | NUT M8X1,25 |
| 5 | 16043224 | SCREW M8X16 MM |
| 6 | 8112423 | RETAINER |
| 7 | 16043521 | SCREW M8X22 |
| 8 | 4775924 | RETAINER |
| 9 | 16605524 | HEXAGON BOLT M8X20 MM |
| 10 | 4807308 | DELIVERY LINE |
| 11 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 12 | 17088474 | WASHER Ø6X12 MM |
| 13 | 17090271 | WASHER Ø10X20X2,6 MM |
| 15 | 17282181 | O-RING Ø21,8 MM SP=2,6 MM |
| 16 | 16605424 | SCREW M8X16 MM (8.8) |
| 17 | 16043524 | SCREW M8X22 MM |
