8061i05.05
A28010029/02 ELECTRONIC GOVERNOR WOODWARD - 24V
| Item | Part number | Description |
|---|---|---|
| 1 | 8108716 | NUT |
| 2 | 10278650 | GASKET Ø16X22X1 MM |
| 3 | 10300711 | LOCK PLUG M16 |
| 4 | 11197779 | SPRING WASHER Ø6X12 MM |
| 5 | 4934404 | SCREW |
| 6 | 14309220 | SCREW |
| 7 | 16689177 | SOCKET-HEAD SCREW M6X16 MM |
| 8 | 8007453 | SUPPORT |
| 9 | 773353 | GASKET |
| 10 | 8108613 | FLANGE |
| 11 | 10717311 | NUT M12 |
| 12 | 772277 | SHIM SP=1,2 MM |
| 13 | 772278 | SHIM SP=1,5 MM |
| 14 | 772279 | SHIM SP=1,8 MM |
| 15 | 772280 | SHIM SP=2,00 MM |
| 16 | 8109360 | SCREW M5X12 |
| 17 | 8108604 | PIN |
| 18 | 10977821 | HEXAGON BOLT M5X16 MM |
| 19 | 8108602 | GASKET |
| 20 | 8007646 | SPACING BAR |
| 21 | 8007452 | COVER ASSY |
| 22 | 8108601 | LEVER |
| 23 | 8109731 | PIN |
| 24 | 8109732 | WASHER |
| 25 | 14158570 | DOWEL PIN Ø2,3 MM |
| 26 | 14497801 | WASHER Ø5X9,5 MM |
| 27 | 8013188 | WASHER |
| 28 | 16979331 | HEXAGON NUT M6X1 |
| 29 | 8108715 | SCREW |
| 30 | 15896411 | HEXAGON NUT M5 |
| 31 | 12574111 | HEXAGON NUT M5 |
| 32 | 8011089 | INJECTION LINE |
| 33 | 98474308 | SEAL GASKET Ø14X22 MM |
| 34 | 8108944 | ELECTROVALVE |
| 35 | 4929627 | PIPE SOCKET |
| 36 | 4929626 | PIPE SOCKET |
| 37 | 8011090 | INJECTION LINE |
| 38 | 10182817 | LOCK PLUG |
| 39 | 61320123 | SCREW CONNECTOR |
| 40 | 4858608 | SEAL GASKET dia.14x19,5x1,5 |
