| Item |
Part number |
Description |
|
1 |
4936436 |
SUPPORT |
|
2 |
4790881 |
THERMOSTAT BODY |
|
3 |
15971621 |
HEXAGON BOLT M10X1,25X90 MM |
|
4 |
15972621 |
HEXAGON BOLT M10X1,25X140 MM |
|
5 |
11198371 |
SPRING WASHER Ø10X20 MM |
|
6 |
14323811 |
LOCK PLUG Ø20 MM SP=1,5 MM |
|
7 |
4774435 |
GASKET |
|
8 |
16043621 |
HEXAGON BOLT M8X25 MM |
|
9 |
4599809 |
FLAT ENGINE GASKET |
|
10 |
14463281 |
O-RING Ø3,53X24,99 MM |
|
11 |
4774405 |
PIPE [up to 511892] |
|
12 |
13449521 |
STUD M10X15X25 |
|
13 |
4728640 |
SPACING BAR |
|
14 |
4728639 |
GASKET |
|
15 |
12164711 |
HEXAGON NUT M10X1,25 |
|
16 |
38824001 |
GASKET |
|
17 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
|
18 |
4936431 |
WATER PIPE |
|
19 |
11288021 |
HEXAGON BOLT M10X1,25X60 MM |
|
20 |
10300711 |
LOCK PLUG M16 |
|
21 |
10257060 |
SEAL GASKET Ø16X22 MM SP=1,5 MM |
