8061M12.00
A20040016/02 WATER PREHEATER DEVICE - 220V
| Item | Part number | Description |
|---|---|---|
| 1 | 8008375 | HEATER 700W |
| 2 | 8006965 | SUPPORT |
| 3 | 11197779 | SPRING WASHER Ø6X12 MM |
| 4 | 18088392 | CLIP Ø16/25 MM |
| 5 | 8008384 | WATER PIPE |
| 6 | 17764492 | CLIP Ø16-25 MM |
| 7 | 16610524 | HEXAGON BOLT M12X60 MM |
| 8 | 17091074 | WASHER Ø12X24X2,8 MM |
| 9 | 4929462 | SPACING BAR |
| 10 | 8011610 | CONNECTOR SLEEVE |
| 11 | 8009376 | WIRE/CABLE ASSY |
| 12 | 10902121 | HEXAGON BOLT M6X14 MM |
| 13 | 4601938 | THREADED UNION |
| 14 | 8008385 | WATER HOSE |
| 15 | 10280060 | WASHER Ø14X20 MM SP=1,5 MM |
| 16 | 10300640 | LOCK PLUG M14X1,5 |
| 17 | 4929073 | PIPE SOCKET |
