| Item |
Part number |
Description |
|
1 |
8013342 |
INTAKE ELBOW ASSY |
|
2 |
4851921 |
INTAKE ELBOW GASK. |
|
3 |
8006416 |
INTAKE ELBOW |
|
4 |
8018245 |
COVER |
|
5 |
8006421 |
O-RING |
|
6 |
8006419 |
TUBE STACK |
|
7 |
8018246 |
COVER |
|
8 |
8006420 |
SPACING BAR |
|
9 |
17094914 |
WASHER 8x16 |
|
10 |
8025611 |
SCREW M10X25 |
|
11 |
4858607 |
WASHER �12X17 MM SP=1,5 MM |
|
12 |
8025612 |
NUT |
|
13 |
16992511 |
THREADED PLUG M18X1,5 |
|
14 |
4858610 |
WASHER �18X24 MM SP=1,5 MM |
|
15 |
4858606 |
GASKET �10X14X1 MM |
|
16 |
16992111 |
THREADED PLUG M10X1 |
|
17 |
16690824 |
CYLIND-HEAD SCREW M8X35 MM |
|
18 |
17800474 |
WASHER �8X15X1,0 MM |
|
19 |
17037931 |
HEXAGON NUT M8X1,25 |
|
20 |
16729424 |
STUD M8X1,25X25 |
|
21 |
16746624 |
STUD M8X20 MM (8.8) |
|
22 |
8025610 |
PIPE SOCKET |
|
23 |
8017600 |
BALL �10 MM |
|
24 |
10305011 |
PLUG |
|
25 |
98429280 |
SEAL GASKET �20X26 MM SP=1,5 MM |
|
26 |
16992211 |
THREADED PLUG M12X1,5 |
