| Item |
Part number |
Description |
|
1 |
8100229 |
CHOCK |
|
2 |
8100230 |
RETAINER |
|
3 |
8100231 |
RETAINER |
|
4 |
15896211 |
HEXAGON NUT M6 |
|
5 |
17088474 |
WASHER Ø6X12 MM |
|
6 |
8100232 |
OIL LINE |
|
7 |
8108290 |
OIL LINE |
|
8 |
4864079 |
SCREW CONNECTOR M10X1 |
|
9 |
11903040 |
LOCK PLUG M10X1 |
|
10 |
11194079 |
SPRING WASHER Ø8X16 MM SP=1,9 MM |
|
11 |
12179790 |
CLIP Ø14-22 MM |
|
13 |
10284460 |
SEAL GASKET Ø10X16 MM |
|
14 |
11903817 |
SCREW CONNECTOR M10X1,25X19 MM |
|
15 |
16044021 |
HEXAGON BOLT M8X1,25X40 MM |
|
17 |
10300540 |
PLUG M12X1,5 |
|
18 |
10298460 |
SEAL GASKET Ø12X18 MM SP=1,5 MM |
|
19 |
4935362 |
RUBBER SLEEVE |
|
20 |
4935361 |
SCREW CONNECTOR |
|
21 |
8113558 |
OIL LINE |
|
24 |
10260160 |
SEAL GASKET Ø10X14 MM SP=1 MM |
|
25 |
8113559 |
INJECTION LINE |
|
26 |
4599562 |
FLAT ENGINE GASKET |
