| Item |
Part number |
Description |
|
1 |
4809425 |
WASHER Ø50 MM |
|
2 |
4667498 |
WASHER |
|
3 |
4708213 |
CIRCLIP |
|
4 |
4769422 |
INJ.PUMP DRIV.GEA |
|
5 |
4779227 |
SUPPORT ASSY |
|
6 |
4769426 |
INJECT.PUMP SPIND |
|
7 |
4769427 |
BUSH VANDERVELL |
|
8 |
4849996 |
FLAT ENGINE GASKET |
|
9 |
4769430 |
INJECT.PUMP SLEEVE |
|
10 |
4769431 |
INJECT.PUMP BUSH |
|
11 |
4798845 |
SCREW |
|
12 |
4779607 |
ADVANCE UNIT ASSY WEBER ALTECNA |
|
13 |
17085376 |
CIRCLIP Ø30 MM |
|
14 |
17283081 |
O-RING Ø36,17X2,62 MM |
|
15 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
16 |
17094914 |
WASHER 8x16 |
|
17 |
8006589 |
SCREW |
|
18 |
4838261 |
BUSH |
|
19 |
4732693 |
WASHER |
|
20 |
8838914 |
GASKET |
|
21 |
17090474 |
SPRING WASHER Ø10X27 MM SP=2,5 |
|
22 |
4732694 |
NUT |
|
23 |
15970921 |
HEXAGON BOLT M10X1,25X35 MM |
|
24 |
4794007 |
SCREW |
|
25 |
10489510 |
PARALLEL PIN M6X12 MM |
