8065SRE10.00
A18080003/03 AIR COMPRESSOR - if hydraulic pump not fitted - 221cc
| Item | Part number | Description |
|---|---|---|
| 1 | 4842719 | SUPPORT |
| 2 | 98400800 | BELT TENSIONER |
| 3 | 4774408 | PULLEY |
| 4 | 15004021 | HEXAGON BOLT M10X1,25X25 MM |
| 5 | 17090174 | SPRING WASHER Ø10X20 MM |
| 6 | 17037821 | HEXAGON NUT M6X1 |
| 7 | 17088474 | WASHER Ø6X12 MM |
| 8 | 15970921 | HEXAGON BOLT M10X1,25X35 MM |
| 9 | 11343821 | HEXAGON BOLT M10X1,25X50 MM |
| 10 | 15888821 | HEXAGON BOLT M10X1,25X70 MM |
| 11 | 16605924 | SCREW M8X40 MM |
| 12 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
