| Item |
Part number |
Description |
|
1 |
8025588 |
COVER |
|
2 |
16729524 |
STUD M8X1,25X30 |
|
3 |
500318720 |
FLAT ENGINE GASKET Ø50 MM |
|
4 |
500338375 |
FRONT C.CASE COVER ASSY |
|
5 |
500321670 |
TIMINGGEAR HOUSIN ASSY REAR |
|
6 |
98424045 |
FLAT ENGINE GASKET |
|
7 |
98424046 |
FLAT ENGINE GASKET |
|
8 |
98461684 |
OIL RETAINER FRONT |
|
9 |
13526170 |
THREADED INSERT M10X1,25X20 MM |
|
10 |
17094914 |
WASHER 8x16 |
|
11 |
10839610 |
DOWEL PIN Ø8 MM |
|
13 |
17037931 |
HEXAGON NUT M8X1,25 |
|
14 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
15 |
99484972 |
INDICATOR |
|
16 |
16605424 |
SCREW M8X16 MM (8.8) |
|
18 |
4605220 |
OIL NOZZLE |
|
19 |
16606124 |
HEXAGON BOLT M8X50 MM |
|
20 |
16605824 |
HEXAGON BOLT M8X35 MM |
|
21 |
16043521 |
SCREW M8X22 |
|
22 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
23 |
16044921 |
HEXAGON BOLT M8X1,25X85 MM |
|
24 |
16606524 |
HEXAGON BOLT M8X70 MM |
|
27 |
8025809 |
COVER |
|
28 |
98417986 |
FLAT ENGINE GASKET |
|
29 |
500331926 |
FLYWHEEL HOUSING ASSY |
|
30 |
16746824 |
STUD M8X30 MM (8.8) |
|
31 |
16612324 |
HEXAGON BOLT M14X35 MM |
|
32 |
17275510 |
DOWEL PIN Ø10 MM |
|
33 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
34 |
4602520 |
PLUG |
|
35 |
10297760 |
SEAL GASKET Ø6,2 MM |
|
36 |
4619671 |
SUPPORT |
|
37 |
4851004 |
FLAT ENGINE GASKET |
|
38 |
15213824 |
HEXAGON BOLT M8X65 MM |
|
40 |
13516821 |
STUD M8X12X20 MM |
|
41 |
11200171 |
SPRING WASHER Ø15 MM |
|
42 |
11306921 |
SCREW M10X1,25X30 |
|
43 |
99457401 |
SHAFT SEAL CORCOS |
|
44 |
17038721 |
NUT M14X2 [from ...] |
|
45 |
16998011 |
PLUG M35X1,5 |
|
48 |
16729624 |
STUD M8X35 |
|
49 |
8005646 |
RETAINER |
|
50 |
99469265 |
SHAFT SEAL CORCOS |
