8140.43.3931
0710.122 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 4843705 | INTAKE ELBOW |
| 2 | 98425767 | INTAKE ELBOW GASK. SP=0,8 MM |
| 3 | 99443396 | EXH. MANIFOLD GKT |
| 4 | 99486343 | HEXAGON NUT M8X1,25 |
| 5 | 99454792 | INTAKE ELBOW |
| 6 | 98426170 | FLAT ENGINE GASKET SP=0,8 MM |
| 7 | 16690724 | CYLIND-HEAD SCREW M8X30 MM |
| 8 | 17094924 | WASHER Ø8X16 MM |
| 9 | 1134045 | PLUG |
| 10 | 1118647 | WASHER Ø8X11,5 MM |
| 11 | 16746734 | STUD M8X25 MM |
