8140.43.3931
3000.042 OIL PUMP
| Item | Part number | Description |
|---|---|---|
| 1 | 4856602 | KIT-OIL PUMP GEARS |
| 2 | 500309868 | COVER [up to 2384045] |
| 3 | 14326001 | THREADED PLUG M10X1,25 |
| 4 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 5 | 16605924 | SCREW M8X40 MM |
| 6 | 16606124 | HEXAGON BOLT M8X50 MM |
| 7 | 16043724 | HEXAGON BOLT M8X28 MM (8.8) |
| 8 | 500354826 | COVER [up to 2689494] |
| 9 | 500334155 | COVER [from 2689495] |
| 11 | 17042531 | HEXAGON NUT M8 |
| 12 | 13516921 | STUD M8X12X22 MM |
