| Item |
Part number |
Description |
|
1 |
4600631 |
STUD |
|
2 |
98473354 |
BRACKET RIGHT [from 1739717] |
|
3 |
4710945 |
BUSH Ø18X30 MM |
|
4 |
4837071 |
FASTENING BRACKET |
|
5 |
4755220 |
O-RING Ø22,22 MM SP=2,62 MM |
|
6 |
4755221 |
O-RING Ø17,86 MM SP=2,62 MM |
|
7 |
4658608 |
GASKET |
|
8 |
15971321 |
HEXAGON BOLT M10X1,25X75 MM |
|
9 |
99458260 |
SCREW M12X1,5X150 MM |
|
10 |
10263360 |
SEAL GASKET 20x26x1 |
|
11 |
10305071 |
LOCK PLUG M20X1,5 [up to ...] |
|
12 |
16289124 |
HEXAGON BOLT M10X1,25X60 MM |
|
13 |
7300716 |
LOCKING PLATE |
|
14 |
16289624 |
HEXAGON BOLT M10X1,25X100 MM |
|
15 |
16603824 |
SCREW M6X25 |
|
16 |
99442682 |
HOUSING |
|
17 |
7301015 |
COVER |
|
18 |
16606024 |
SCREW M8X45 MM |
|
19 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
20 |
16689224 |
SOCKET-HEAD SCREW M6X20 MM |
|
21 |
17037931 |
HEXAGON NUT M8X1,25 |
|
22 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
23 |
7301019 |
FLAT ENGINE GASKET |
|
24 |
17094914 |
WASHER 8x16 |
|
25 |
98421263 |
FLAT ENGINE GASKET SP=0,5 MM |
|
26 |
7301025 |
PLASTIC PLUG |
|
27 |
98421262 |
FLAT ENGINE GASKET |
|
28 |
4741749 |
SCREW |
|
29 |
98454041 |
OIL RETAINER |
|
30 |
99468007 |
COVER ASSY REAR |
|
31 |
7301026 |
FASTENING BRACKET |
|
32 |
16689124 |
CYLIND-HEAD SCREW M6X16 MM |
|
33 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
34 |
98461177 |
BUSH Ø40X46,2 MM [from 1608990] |
|
35 |
98461178 |
O-RING Ø46,04 MM SP=3,53 MM |
|
36 |
98465476 |
DOWEL PIN Ø8 MM |
|
37 |
98468138 |
HEXAGON BOLT M8X1,25X150 MM |
|
38 |
99446916 |
SUPPORT ASSY |
|
39 |
99467535 |
FLANGE ASSY |
|
40 |
7303101 |
COVER TOP |
|
41 |
99452520 |
BRACKET RIGHT |
|
42 |
16979731 |
NUT M10X1,25 |
|
43 |
11500021 |
STUD M6X9 MM |
|
45 |
11500821 |
STUD |
|
46 |
17849770 |
THREADED INSERT M8X16 MM |
|
47 |
16603724 |
HEXAGON BOLT M6X20 MM (8.8) |
|
48 |
17094714 |
WASHER Ø6,4X12 MM |
|
49 |
17816314 |
SPACING BAR Ø8,5X18 MM SP=15 MM |
|
50 |
14328101 |
LOCK PLUG Ø8 MM |
|
51 |
17290281 |
O-RING Ø63,09 MM SP=3,53 MM |
|
52 |
14466081 |
O-RING Ø101,19 MM SP=3,53 |
|
53 |
16707034 |
CYLIND-HEAD SCREW M8X16 MM |
|
54 |
17089574 |
WASHER Ø8X16 MM |
|
55 |
16043324 |
HEXAGON BOLT M8X18 MM |
|
56 |
10902124 |
SCREW M6X14 MM |
|
58 |
99447458 |
COVER [from 2122563] |
|
59 |
16980131 |
HEXAGON NUT M12 |
|
60 |
16605924 |
SCREW M8X40 MM |
|
61 |
17037821 |
HEXAGON NUT M6X1 |
|
62 |
17088474 |
WASHER Ø6X12 MM |
|
63 |
17090274 |
WASHER Ø10X20 MM |
|
64 |
17281581 |
O-RING Ø12,37X2,62 MM |
|
65 |
17282281 |
O-RING 2,62x23,47 |
|
66 |
98421270 |
FLAT ENGINE GASKET |
|
67 |
98421271 |
FLAT ENGINE GASKET |
|
68 |
98421284 |
FLAT ENGINE GASKET |
|
69 |
98421292 |
FLAT ENGINE GASKET SP=0,8 MM |
