8141i67.01
A05040001 INTAKE MANIFOLD - front axial inlet
| Item | Part number | Description |
|---|---|---|
| 1 | 7301885 | INTAKE ELBOW |
| 2 | 4279436 | INTAKE ELBOW GASK. |
| 3 | 10263160 | SEAL GASKET Ø18X24 MM SP=1 MM |
| 4 | 16102011 | HEXAGON NUT M18X1 |
| 5 | 7302320 | PIPE SOCKET |
| 6 | 13417608 | CLIP Ø25,6 MM |
| 7 | 7302256 | RETAINER |
| 8 | 11194071 | WASHER Ø8X16X1,9 MM |
| 9 | 10902021 | HEXAGON BOLT M6X12 MM |
| 10 | 7302255 | RUBBER SLEEVE |
| 11 | 11194371 | SPRING WASHER Ø6,4 MM |
| 12 | 7302252 | FASTENING BRACKET |
