| Item |
Part number |
Description |
|
1 |
98433754 |
RUBBER SLEEVE |
|
2 |
4822221 |
WATER HOSE |
|
3 |
98433796 |
WATER PIPE |
|
4 |
98433784 |
WATER PIPE |
|
5 |
17037931 |
HEXAGON NUT M8X1,25 |
|
6 |
98447076 |
PIPE SOCKET |
|
7 |
99443116 |
RUBBER SLEEVE |
|
8 |
99441774 |
RUBBER SLEEVE |
|
9 |
98433830 |
WATER PIPE |
|
10 |
98430478 |
FLAT ENGINE GASKET SP=1,6 MM |
|
11 |
17737487 |
WATER HOSE |
|
12 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
13 |
8107339 |
PLUG |
|
14 |
98463347 |
CLIP Ø18,5-25 MM |
|
15 |
13543521 |
STUD M8X16X25 MM |
|
16 |
11198374 |
SPRING WASHER Ø10X20 MM |
|
17 |
15970521 |
HEXAGON BOLT M10X20 MM |
|
18 |
98457742 |
RETAINER |
|
19 |
11190774 |
SPRING WASHER |
|
20 |
15540324 |
SCREW M12X1,25X25 |
|
21 |
4933019 |
TRANSMITTER TTA - TTO |
|
22 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
