| Item |
Part number |
Description |
|
6 |
4279804 |
RING GEAR |
|
7 |
4655844 |
KEY |
|
8 |
98473342 |
PISTON PIN |
|
9 |
4758576 |
SPRING LOCKWASHER |
|
10 |
500329617 |
BIG-END BUSH [FROM # 2572280] |
|
11 |
500352497 |
CONN.ROD ASSY. ASSY [FROM # 2572280] |
|
12 |
10332010 |
PARALLEL PIN |
|
13 |
14328101 |
LOCK PLUG Ø8 MM |
|
14 |
98419310 |
GEAR ASSY |
|
15 |
98426210 |
ENGINE BEARINGS Ø15X35 Sp=14 MM |
|
16 |
98426373 |
CENTERING RING [from 1307401] |
|
17 |
98428116 |
DOWEL PIN |
|
18 |
98430735 |
SCREW |
|
19 |
98460577 |
BIG-END BOLT |
|
20 |
500382144 |
FLYWHEEL |
|
21 |
500329821 |
CRANK SHAFT ASSY |
|
24 |
99473771 |
MAIN BEARING SET STD |
|
25 |
99473772 |
MAIN BEAR.SET -0,254 |
|
26 |
99473773 |
MAIN BEAR.SET -0,508 |
|
27 |
99474279 |
CON.ROD BEAR STD. |
|
28 |
99474280 |
CON.ROD BEAR-0,254 |
|
29 |
99474281 |
CON.ROD BEAR-0,508 |
|
30 |
2992046 |
PISTONRING SET STD |
|
31 |
2992047 |
PISTONRING SET+0.4 |
|
32 |
2992454 |
PISTON ASSY |
|
33 |
2992455 |
PISTON ASSY. +0.4 |
