8210i03.00
A28010013/02 ELECTRONIC GOVERNOR WOODWARD - 24V

Iveco/FPT ELECTRONIC GOVERNOR WOODWARD

Item Part number Description
1 16992411 THREADED PLUG M16X1,5
2 4858609 WASHER Ø16X22 MM SP=1,5 MM
3 10717311 NUT M12
4 17088474 WASHER Ø6X12 MM
5 4934404 SCREW
6 16689134 SOCKET-HEAD SCREW M6X16 MM
7 16689177 SOCKET-HEAD SCREW M6X16 MM
8 8007450 TIMINGGEAR HOUSIN
9 8108716 NUT
10 8015485 GASKET
11 12574011 NUT M4
12 10374811 CYLIND-HEAD SCREW M4X10 MM
13 14158570 DOWEL PIN Ø2,3 MM
14 8108602 GASKET
15 8108601 LEVER
16 8007452 COVER ASSY
17 8108604 PIN
18 14497801 WASHER Ø5X9,5 MM
19 12574111 HEXAGON NUT M5
20 8109360 SCREW M5X12
21 8109731 PIN
22 8109732 WASHER
24 17037721 NUT M5X0,8
25 8108715 SCREW
26 8018344 FUEL LINE [from 07-94]
27 10182817 LOCK PLUG
28 61608319 SCREW CONNECTOR
29 4858608 SEAL GASKET dia.14x19,5x1,5
30 4929626 PIPE SOCKET
31 8108944 ELECTROVALVE
32 8020658 FUEL LINE
33 4936577 SCREW CONNECTOR
