8210SRE20.00
A01050021/04 OIL SUMP - max longitudinal inclination 45°
| Item | Part number | Description |
|---|---|---|
| 1 | 4706072 | OIL LINE |
| 2 | 4864035 | FLAT ENGINE GASKET |
| 3 | 17090274 | WASHER Ø10X20 MM |
| 4 | 16605424 | SCREW M8X16 MM (8.8) |
| 5 | 4706070 | RETAINER |
| 6 | 4706071 | RETAINER |
| 7 | 1366290 | RUBBER LUG |
| 8 | 17089774 | SPRING WASHER Ø8,4X22 MM SP=2,4 MM |
| 9 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 10 | 17087921 | NUT |
| 11 | 4618810 | RETAINER |
| 12 | 1367840 | RETAINER |
| 13 | 15970524 | HEXAGON BOLT M10X1,25X20 |
| 14 | 16605524 | HEXAGON BOLT M8X20 MM |
| 15 | 16605734 | HEXAGON BOLT M8X30 MM |
| 16 | 16606024 | SCREW M8X45 MM |
| 17 | 4864034 | FLAT ENGINE GASKET |
| 18 | 1367839 | SUCTION STRAINER |
