| Item |
Part number |
Description |
|
1 |
8017857 |
WATER PIPE |
|
2 |
8017856 |
WATER PIPE |
|
3 |
17745887 |
RUBBER SLEEVE WATER |
|
4 |
4830091 |
CLIP |
|
5 |
18087991 |
CLIP Ø8/16 MM |
|
6 |
19056687 |
RUBBER HOSE Ø7,5 MM |
|
7 |
8090977 |
KIT-RADIATOR A.S. COMPLETE |
|
8 |
8019388 |
TIE ROD |
|
9 |
17038421 |
HEXAGON NUT M12 (8) |
|
10 |
8100819 |
RETAINER |
|
11 |
4936328 |
CLIP ASSY |
|
12 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
13 |
4565875 |
RUBBER PAD |
|
14 |
11306921 |
SCREW M10X1,25X30 |
|
15 |
17091374 |
SPRING WASHER Ø12X30X3,0 MM |
|
16 |
17095304 |
WASHER Ø12X24 MM |
|
17 |
8020013 |
CLIP |
|
18 |
42088612 |
WATER HOSE |
|
19 |
8019766 |
AIR PIPE/DUCT |
|
20 |
8019387 |
RETAINER |
|
21 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
22 |
8108759 |
CLIP |
|
23 |
1366290 |
RUBBER LUG |
|
24 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
25 |
17037931 |
HEXAGON NUT M8X1,25 |
|
27 |
17038121 |
HEXAGON NUT M10 |
|
28 |
8017858 |
AIR PIPE/DUCT |
|
29 |
16748524 |
STUD M10X25 MM (8.8) |
|
30 |
17291481 |
O-RING Ø101,19 MM SP=3,53 |
|
31 |
8019386 |
RETAINER |
|
32 |
42070016 |
WATER HOSE |
|
33 |
8005839 |
CLIP |
