| Item |
Part number |
Description |
|
1 |
4792306 |
FRONT C.CASE COVER ASSY |
|
2 |
4756344 |
PLATE |
|
3 |
99431449 |
FLAT ENGINE GASKET |
|
4 |
98462005 |
GASKET |
|
5 |
4679631 |
OIL LINE |
|
6 |
852410 |
FASTENING BRACKET |
|
7 |
4707984 |
SCREW CONNECTOR |
|
8 |
10262760 |
SEAL GASKET Ø8,2 MM |
|
9 |
13550301 |
WASHER Ø8,15 MM |
|
10 |
16042921 |
SCREW M8X10 |
|
11 |
4679620 |
SCREW CONNECTOR |
|
12 |
852409 |
LOCKING PLATE Ø10,5 MM |
|
13 |
10279460 |
SEAL GASKET Ø10X16 MM SP=0,5 |
|
16 |
4547528 |
COVER |
|
17 |
4863975 |
FLAT ENGINE GASKET |
|
18 |
15970524 |
HEXAGON BOLT M10X1,25X20 |
|
19 |
17090274 |
WASHER Ø10X20 MM |
|
20 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
|
21 |
10837810 |
DOWEL PIN Ø12 MM |
|
22 |
17038221 |
HEXAGON NUT M10 |
|
23 |
11288024 |
HEXAGON BOLT M10X1,25X60 MM |
|
24 |
14496604 |
WASHER Ø10X21 MM |
|
25 |
15971724 |
HEXAGON BOLT M10X1,25X95 MM |
|
27 |
98467211 |
WASHER FRONT |
|
28 |
12163921 |
HEXAGON NUT M12X1,5 |
|
29 |
12646924 |
WASHER Ø12X28 MM |
|
30 |
16045121 |
HEXAGON BOLT M8X95 MM |
|
31 |
10519621 |
WASHER Ø8,45 MM |
|
32 |
13453721 |
STUD M10X25X30 |
|
34 |
13449330 |
STUD M10X15X20 MM |
|
38 |
10837610 |
DOWEL PIN Ø8 MM |
|
40 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
41 |
16606324 |
HEXAGON BOLT M8X60 MM |
|
42 |
16606624 |
HEXAGON BOLT M8X80 MM |
|
43 |
4721702 |
STUD |
|
44 |
16606424 |
HEXAGON BOLT M8X65 MM |
