| Item |
Part number |
Description |
|
1 |
8012899 |
WATER PIPE |
|
2 |
8015164 |
SCREW CONNECTOR |
|
3 |
4930504 |
SCREW CONNECTOR |
|
4 |
98433829 |
BANJO COUPLING [up to 1555507] |
|
5 |
98474306 |
WASHER Ø12X20 MM SP=1,9 MM |
|
6 |
4858606 |
GASKET Ø10X14X1 MM |
|
7 |
4871068 |
PLUG ASSY |
|
8 |
98427299 |
WATER MANIFOLD |
|
9 |
99435380 |
FLAT ENGINE GASKET Ø50 MM |
|
10 |
8113491 |
WATER PIPE |
|
11 |
15888734 |
HEXAGON BOLT M10X1,25X55 MM |
|
12 |
17095114 |
WASHER Ø10X21 MM |
|
13 |
98421377 |
RUBBER SLEEVE Ø51 MM |
|
14 |
17764992 |
CLIP Ø50-70 MM |
|
15 |
10260360 |
SEAL GASKET Ø24,3 MM |
|
16 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
17 |
8111243 |
WATER PIPE |
|
18 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
19 |
4858610 |
WASHER Ø18X24 MM SP=1,5 MM |
|
20 |
4630360 |
THREADED UNION |
|
21 |
98474305 |
WASHER Ø10X17 MM SP=2,3 |
|
22 |
8009699 |
SCREW CONNECTOR |
|
23 |
4778955 |
WATER MANIFOLD |
|
24 |
4762646 |
WATER MANIFOLD |
|
25 |
4641230 |
WATER MANIFOLD |
|
26 |
500308780 |
FLAT ENGINE GASKET |
|
27 |
16605824 |
HEXAGON BOLT M8X35 MM |
|
28 |
4852210 |
WASHER |
|
29 |
4852211 |
WASHER |
|
30 |
16606024 |
SCREW M8X45 MM |
|
31 |
4852099 |
FLAT ENGINE GASKET |
|
32 |
16605924 |
SCREW M8X40 MM |
|
33 |
4762647 |
CONNECTOR SLEEVE |
|
34 |
98458442 |
O-RING Ø24,99 MM SP=3,53 MM [from 657424] |
|
35 |
4863947 |
FLAT ENGINE GASKET |
|
36 |
1365519 |
FLANGE |
|
37 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
38 |
17094914 |
WASHER 8x16 |
|
39 |
16997411 |
THREADED PLUG M16X1,5 |
|
40 |
16997311 |
PLUG M14X1,5 |
|
41 |
4799657 |
WATER PIPE |
|
42 |
16992311 |
LOCK PLUG M14X1,5 |
|
43 |
98461201 |
O-RING |
|
44 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
45 |
99456733 |
FLAT ENGINE GASKET |
|
46 |
17089574 |
WASHER Ø8X16 MM |
