8210SRM45.31
3010.137/02 LUBE OIL LINES

Iveco/FPT LUBE OIL LINES

Item Part number Description
1 98443555 PIPE
2 98474954 PIPE
3 8020612 OIL LINE
4 8013632 OIL LINE
5 17089474 SPRING WASHER Ø8X16 MM SP=1,4 MM
6 17090174 SPRING WASHER Ø10X20 MM
7 16605424 SCREW M8X16 MM (8.8)
8 4645737 FASTENING BRACKET
9 61320123 SCREW CONNECTOR
10 4621393 THREADED UNION
11 11902117 PLUG M10X1,25
12 17316190 PIPE CLIP Ø6 MM
13 4864079 SCREW CONNECTOR M10X1
14 98474305 WASHER Ø10X17 MM SP=2,3
15 4837613 GASKET [up to ...]
16 98474308 SEAL GASKET Ø14X22 MM
17 98479387 SCREW CONNECTOR [from 301968]
18 15004021 HEXAGON BOLT M10X1,25X25 MM
19 17316490 CLIP
20 98474306 WASHER Ø12X20 MM SP=1,9 MM
21 4864082 BANJO BOLT M12X1,5X25 MM
22 4755963 FASTENING BRACKET
23 4755964 RUBBER PAD
24 4644288 CLIP
25 4644289 CLIP
26 4871771 RUBBER LUG
27 16603924 HEXAGON BOLT M6X30 MM
28 17088474 WASHER Ø6X12 MM
29 17037821 HEXAGON NUT M6X1
