| Item |
Part number |
Description |
|
1 |
4807818 |
AIR PIPE/DUCT |
|
2 |
4807819 |
AIR PIPE/DUCT M6 |
|
3 |
4807822 |
AIR PIPE/DUCT |
|
4 |
99465744 |
AIR PIPE/DUCT [from 307843] |
|
5 |
99447188 |
AIR PIPE/DUCT [from 307843] |
|
6 |
13516621 |
STUD M8X16 MM |
|
7 |
4807826 |
RETAINER |
|
8 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
9 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
10 |
17037931 |
HEXAGON NUT M8X1,25 |
|
11 |
14471781 |
O-RING Ø66 MM SP=5,33 MM |
|
12 |
98420479 |
WATER HOSE |
|
13 |
17764891 |
CLIP Ø40/60 MM |
|
14 |
17291181 |
O-RING Ø91,67 MM SP=3,53 MM |
|
15 |
16605924 |
SCREW M8X40 MM |
|
16 |
17094914 |
WASHER 8x16 |
|
17 |
13517021 |
STUD M8X25 MM |
|
21 |
4807824 |
PIPE CLIP |
