8281SRi10.00
3280.004 WATER FILTER

Iveco/FPT WATER FILTER

Item Part number Description
1 1901776 WATER FILTER CARTRIDGE
2 4696152 SUPPORT
3 15980321 HEXAGON BOLT M16X1,5X25 MM
4 4681777 THREADED UNION
5 8010846 WATER PIPE
6 8010847 WATER PIPE
7 4858608 SEAL GASKET dia.14x19,5x1,5
8 4864083 SCREW CONNECTOR M14X1,5X30 MM
9 17090179 WASHER Ø10X20X2,6 MM
10 16607624 SCREW M10X25
11 17038121 HEXAGON NUT M10
12 17092174 SPRING WASHER Ø16X32X3,4
13 4771771 DOWEL
14 4644289 CLIP
15 4936558 RETAINER
16 16603824 SCREW M6X25
17 17088974 SPRING WASHER Ø6X18X1,4 MM
18 4644288 CLIP
