| Item |
Part number |
Description |
|
1 |
8012556 |
FUEL LINE |
|
2 |
8008513 |
FUEL LINE |
|
3 |
8008512 |
INJECTION LINE |
|
4 |
8012522 |
FUEL LINE |
|
5 |
98404882 |
PIPE SOCKET Ø8 MM |
|
6 |
61608319 |
SCREW CONNECTOR |
|
7 |
8017500 |
ELECTROVALVE [from 04-94] |
|
8 |
17281581 |
O-RING Ø12,37X2,62 MM |
|
9 |
16603824 |
SCREW M6X25 |
|
10 |
17088474 |
WASHER Ø6X12 MM |
|
11 |
4644288 |
CLIP |
|
12 |
4871771 |
RUBBER LUG |
|
13 |
4644289 |
CLIP |
|
14 |
4864083 |
SCREW CONNECTOR M14X1,5X30 MM |
|
15 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
18 |
98413896 |
PIPE SOCKET Ø8 MM |
|
19 |
8006339 |
CAP |
|
20 |
16508711 |
NUT M14X1,5 [from 05-92] |
