| Item |
Part number |
Description |
|
1 |
8113781 |
MARINE GEAR OIL HEAT EXCH ASSY |
|
2 |
8111709 |
HEAT EXCHANG.COVER |
|
3 |
8113627 |
WATER PIPE [up to 09-91] |
|
4 |
8105276 |
PLUG M16 |
|
5 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
6 |
16509011 |
NUT M22X1,5X7 MM |
|
7 |
14463681 |
O-RING SP=3,53 MM |
|
8 |
14461081 |
O-RING |
|
9 |
14306521 |
CYLIND-HEAD SCREW M8X30 MM |
|
10 |
10571771 |
SPRING WASHER Ø8 MM |
|
11 |
11903140 |
PLUG M10X1,25 |
|
12 |
8113782 |
MARINE GEAR OIL HEAT EXCH |
|
13 |
10260160 |
SEAL GASKET Ø10X14 MM SP=1 MM |
|
15 |
8105277 |
SACRIFICAL ANODE Ø14 MM |
|
17 |
8112229 |
OIL LINE |
|
18 |
8112230 |
OIL LINE |
|
19 |
8113790 |
PIPE SOCKET [up to 08-94] |
|
20 |
8111750 |
RETAINER |
|
21 |
8111751 |
PIPE SOCKET |
|
22 |
16044121 |
HEXAGON BOLT M8X45 MM (8.8) |
|
23 |
13605911 |
SPACER SP=8,5 MM |
|
24 |
17037931 |
HEXAGON NUT M8X1,25 |
|
25 |
16043021 |
HEXAGON BOLT M8X12 MM |
|
26 |
8113786 |
ENGINE HARNESS GND |
|
27 |
8111561 |
RETAINER |
|
28 |
8111562 |
RETAINER |
|
30 |
8112478 |
WATER PIPE |
|
32 |
14306621 |
SCREW M8X35 |
|
33 |
14306821 |
CYLIND-HEAD SCREW M8X45 MM |
|
34 |
14464580 |
O-RING SP=3,53 MM |
|
35 |
8112496 |
CONNECTION L=90 MM |
|
36 |
16043521 |
SCREW M8X22 |
|
37 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
