| Item |
Part number |
Description |
|
1 |
16991370 |
LOCK PLUG Ø45 MM |
|
2 |
8009883 |
PIPE SOCKET M28X1,5/M14X1,5 |
|
3 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
4 |
16992315 |
THREADED PLUG M14X1,5 |
|
5 |
16997911 |
PLUG M28X1,5 |
|
6 |
1903630 |
OIL FILTER CARTRIDGE KIT |
|
7 |
4741301 |
THREADED UNION ASSY |
|
8 |
17285681 |
O-RING Ø88,57 MM SP=2,62 MM |
|
9 |
16994111 |
PLUG M24X1,5 |
|
10 |
16993511 |
LOCK PLUG M28X1,5 |
|
11 |
98429281 |
SEAL GASKET Ø24X31 MM SP=1,5 MM |
|
12 |
10296260 |
SEAL GASKET Ø28X36 MM SP=1,5 MM |
|
13 |
17284081 |
O-RING |
|
14 |
17282781 |
O-RING Ø31,42 MM SP=2,62 MM |
|
15 |
16729224 |
STUD M8X16 MM |
|
16 |
17037931 |
HEXAGON NUT M8X1,25 |
|
17 |
8026633 |
COVER |
|
18 |
8026635 |
GASKET |
|
20 |
16607524 |
HEXAGON BOLT M10X1,5X20 MM (8.8) |
|
21 |
17095104 |
WASHER Ø10X21X2 MM |
|
22 |
16606124 |
HEXAGON BOLT M8X50 MM |
|
23 |
16606324 |
HEXAGON BOLT M8X60 MM |
|
24 |
16606924 |
SCREW M8X110 |
|
25 |
16607024 |
HEXAGON BOLT M8X120 MM |
|
26 |
17089574 |
WASHER Ø8X16 MM |
|
27 |
17038221 |
HEXAGON NUT M10 |
|
29 |
13953521 |
STUD |
|
30 |
500351609 |
SENSOR OIL PRESSURE [UP TO # 50367] |
|
31 |
17090474 |
SPRING WASHER Ø10X27 MM SP=2,5 |
|
32 |
11288024 |
HEXAGON BOLT M10X1,25X60 MM |
|
33 |
15971424 |
HEXAGON BOLT M10X80 MM |
|
34 |
17282281 |
O-RING 2,62x23,47 |
|
35 |
4824764 |
VALVE HOUSING |
|
36 |
4672842 |
VALVE |
|
37 |
4677094 |
SPRING |
|
38 |
17282581 |
O-RING Ø28,24 MM SP=2,62 MM |
|
39 |
4676507 |
COVER |
|
40 |
17089874 |
WASHER Ø8X22 MM |
