| Item |
Part number |
Description |
|
1 |
8018181 |
FUEL LINE |
|
2 |
8018191 |
FUEL LINE |
|
3 |
8018183 |
FUEL LINE |
|
4 |
8018182 |
FUEL LINE |
|
5 |
8011304 |
PIPE SOCKET |
|
6 |
8018220 |
VALVE |
|
7 |
8018203 |
PIPE SOCKET |
|
8 |
11270260 |
SEAL GASKET Ø14X18 MM |
|
9 |
11271460 |
GASKET Ø21X26X1,5 MM |
|
10 |
8018215 |
PIPE SOCKET |
|
11 |
8011455 |
RETAINER |
|
12 |
8025297 |
PIPE SOCKET |
|
13 |
16508711 |
NUT M14X1,5 [from 05-92] |
|
14 |
8006339 |
CAP |
|
15 |
17281581 |
O-RING Ø12,37X2,62 MM |
|
16 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
17 |
16504011 |
PIPE SOCKET |
|
18 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
19 |
16607724 |
HEXAGON BOLT M10X1,5X30 MM (8.8) |
|
20 |
16607624 |
SCREW M10X25 |
|
21 |
4797319 |
HAND PUMP ASSY |
|
22 |
7300648 |
LOCKING PLATE |
|
23 |
16603824 |
SCREW M6X25 |
|
24 |
16500214 |
THREADED UNION M14X1,5/M16X1,5 |
|
25 |
16603724 |
HEXAGON BOLT M6X20 MM (8.8) |
|
26 |
17088474 |
WASHER Ø6X12 MM |
|
27 |
4755435 |
RETAINER |
|
28 |
4755436 |
RETAINER |
|
29 |
8018192 |
RETAINER |
|
30 |
8011138 |
PIPE SOCKET 1/2''/M16X1,5 |
|
31 |
8010502 |
PIPE SOCKET M22X1,5 |
|
32 |
8011326 |
FUEL LINE |
|
33 |
8011325 |
FUEL LINE |
|
34 |
16508911 |
NUT M18X1,5 |
|
35 |
16509011 |
NUT M22X1,5X7 MM |
|
36 |
16665404 |
WASHER Ø6X12X1,6 MM |
|
37 |
8031212 |
SPACING BAR |
