| Item |
Part number |
Description |
|
1 |
8018399 |
SUPPORT |
|
2 |
8019662 |
RETAINER |
|
3 |
8018446 |
RETAINER |
|
4 |
16608124 |
HEXAGON BOLT M10X1,5X50 MM |
|
5 |
17090174 |
SPRING WASHER �10X20 MM |
|
6 |
4677044 |
SPACING BAR |
|
7 |
17152921 |
HEXAGON NUT M10X1,5 |
|
8 |
8018372 |
RETAINER |
|
9 |
4606783 |
PULLEY |
|
10 |
4606786 |
CENTERING PIN |
|
11 |
4684446 |
RING |
|
12 |
4606789 |
WASHER |
|
13 |
4627792 |
COVER |
|
14 |
4684447 |
SPACING BAR |
|
15 |
28996660 |
BALL BEARING |
|
16 |
16873476 |
CIRCLIP �56,2X2 MM |
|
17 |
17159071 |
NUT |
|
18 |
16605424 |
SCREW M8X16 MM (8.8) |
|
19 |
4723469 |
SET OF V-BELTS |
|
20 |
8110133 |
SUPPORT |
|
21 |
4699000 |
NUT |
|
22 |
4699001 |
TIE ROD |
|
23 |
4699549 |
CLIP |
|
24 |
4513436 |
SUPPORT RING �10X21X2 MM |
|
25 |
17081976 |
CIRCLIP |
|
27 |
16607924 |
HEXAGON BOLT M10X1,5X40 MM |
|
28 |
17089774 |
SPRING WASHER �8,4X22 MM SP=2,4 MM |
|
29 |
17153021 |
HEXAGON NUT M10X1,25 |
|
30 |
16607224 |
SCREW |
|
31 |
17095204 |
WASHER �12X20 MM |
|
32 |
17037921 |
HEXAGON NUT M8X1,25 |
|
33 |
17038421 |
HEXAGON NUT M12 (8) |
|
34 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
35 |
17089474 |
SPRING WASHER �8X16 MM SP=1,4 MM |
|
36 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
