| Item |
Part number |
Description |
|
1 |
8012730 |
OIL SUMP ASSY |
|
2 |
17873271 |
THREADED INSERT M8 |
|
3 |
17873571 |
THREADED INSERT |
|
4 |
11271460 |
GASKET Ø21X26X1,5 MM |
|
5 |
4584394 |
PLUG 1/2'' |
|
6 |
8012859 |
PIPE SOCKET |
|
7 |
98429282 |
SEAL GASKET Ø26X33 MM SP=1,5 MM |
|
8 |
17095004 |
WASHER Ø10X18X2 MM |
|
9 |
15970921 |
HEXAGON BOLT M10X1,25X35 MM |
|
10 |
11234721 |
HEXAGON BOLT M10X1,25X45 MM |
|
11 |
11288024 |
HEXAGON BOLT M10X1,25X60 MM |
|
12 |
15971321 |
HEXAGON BOLT M10X1,25X75 MM |
|
13 |
15005924 |
HEXAGON BOLT M10X1,25X150 MM |
|
14 |
15973321 |
SCREW M10X1,25X175 |
|
15 |
8014700 |
OIL SUMP GASKET |
|
16 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
17 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
18 |
8020774 |
FLANGE |
|
19 |
4889988 |
GASKET |
|
20 |
8019617 |
SPACING BAR |
|
21 |
8019603 |
PLATE |
|
22 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
23 |
16607524 |
HEXAGON BOLT M10X1,5X20 MM (8.8) |
|
24 |
8014037 |
FLANGE |
|
25 |
16992311 |
LOCK PLUG M14X1,5 |
|
26 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
27 |
8011519 |
PIPE SOCKET |
|
28 |
8014089 |
PLUG |
|
29 |
16528060 |
WASHER Ø33X39 MM SP=2 MM |
