| Item |
Part number |
Description |
|
1 |
8020545 |
MARINE GEAR ZF BW 195 - 1:1,086 |
|
2 |
8020675 |
FLANGE |
|
3 |
17289681 |
O-RING �44 MM SP=3,53 MM |
|
4 |
16690624 |
CYLIND-HEAD SCREW M8X25 MM |
|
5 |
8010647 |
FLANGE |
|
6 |
8020570 |
WATER PIPE |
|
7 |
8020571 |
WATER PIPE |
|
8 |
8020678 |
WATER PIPE |
|
9 |
8020679 |
WATER PIPE |
|
10 |
8008755 |
FLAT ENGINE GASKET |
|
12 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
13 |
16606324 |
HEXAGON BOLT M8X60 MM |
|
14 |
17089474 |
SPRING WASHER �8X16 MM SP=1,4 MM |
|
15 |
17289581 |
O-RING �40,87X3,53 MM |
|
16 |
8020546 |
FLEXPLATE |
|
17 |
17093924 |
WASHER �16 MM |
|
18 |
17462134 |
SCREW |
|
19 |
17289981 |
O-RING �53,57X3,53 MM |
|
24 |
8020847 |
RETAINER |
|
25 |
8020682 |
RETAINER |
|
26 |
4936741 |
CLIP |
|
27 |
16607624 |
SCREW M10X25 |
|
28 |
17038121 |
HEXAGON NUT M10 |
|
29 |
17090174 |
SPRING WASHER �10X20 MM |
|
31 |
16610224 |
HEXAGON BOLT M12X1,75X45 MM |
|
32 |
17095304 |
WASHER �12X24 MM |
|
33 |
8023374 |
SUPPORT |
|
34 |
17462034 |
LOCKING SCREW M16X2X40 MM |
