| Item |
Part number |
Description |
|
1 |
8011420 |
WIRE/CABLE |
|
2 |
8111233 |
GASKET |
|
3 |
8010375 |
FUEL LINE |
|
4 |
8112247 |
PIPE SOCKET |
|
5 |
98474306 |
WASHER Ø12X20 MM SP=1,9 MM |
|
6 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
7 |
8011707 |
FUEL LINE |
|
8 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
9 |
4864083 |
SCREW CONNECTOR M14X1,5X30 MM |
|
10 |
4882455 |
OIL LINE |
|
11 |
16504011 |
PIPE SOCKET |
|
12 |
4882459 |
OIL LINE |
|
13 |
98474305 |
WASHER Ø10X17 MM SP=2,3 |
|
14 |
1119237 |
BANJO BOLT M4 |
|
15 |
16689124 |
CYLIND-HEAD SCREW M6X16 MM |
|
16 |
8011590 |
FUEL LINE |
|
17 |
8011711 |
COVER |
|
18 |
16504714 |
T-COUPLING |
|
19 |
16500214 |
THREADED UNION M14X1,5/M16X1,5 |
|
20 |
98474308 |
SEAL GASKET Ø14X22 MM |
