| Item |
Part number |
Description |
|
1 |
8009885 |
OIL LINE |
|
2 |
8009884 |
OIL LINE |
|
3 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
4 |
4864083 |
SCREW CONNECTOR M14X1,5X30 MM |
|
5 |
8008962 |
RETAINER |
|
6 |
4644288 |
CLIP |
|
7 |
4871771 |
RUBBER LUG |
|
8 |
4644289 |
CLIP |
|
9 |
8009886 |
OIL LINE |
|
10 |
8011295 |
PIPE SOCKET |
|
11 |
4858606 |
GASKET Ø10X14X1 MM |
|
12 |
4864080 |
SCREW CONNECTOR M10X1,25 |
|
13 |
4753563 |
PLUG M10X1,5 |
|
14 |
16992440 |
THREADED PLUG M16X1,5 |
|
15 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
16 |
16606324 |
HEXAGON BOLT M8X60 MM |
|
17 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
18 |
17816414 |
SPACING BAR Ø8,5X18 MM SP=20 MM |
|
19 |
17088471 |
SPRING WASHER Ø6X12 MM SP=1,2 MM |
|
20 |
16603924 |
HEXAGON BOLT M6X30 MM |
