| Item |
Part number |
Description |
|
1 |
8010127 |
OIL LINE |
|
2 |
8011269 |
FLANGE |
|
3 |
17288281 |
O-RING Ø18,64X3,53 MM |
|
4 |
4763804 |
FASTENING BRACKET |
|
5 |
8010125 |
OIL LINE |
|
6 |
8010126 |
OIL LINE |
|
7 |
4741608 |
T-COUPLING |
|
8 |
8010539 |
OIL LINE |
|
9 |
8010542 |
PIPE SOCKET |
|
10 |
8010543 |
PIPE SOCKET |
|
11 |
8010546 |
PIPE SOCKET |
|
12 |
4858610 |
WASHER Ø18X24 MM SP=1,5 MM |
|
13 |
4757122 |
RUBBER PAD |
|
14 |
16500311 |
PIPE SOCKET M16X1,5/M18X1,5 |
|
15 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
16 |
17289081 |
O-RING Ø31,34X3,53 MM |
|
17 |
16527914 |
PIPE SOCKET |
|
18 |
16528060 |
WASHER Ø33X39 MM SP=2 MM |
|
19 |
16692124 |
CYLIND-HEAD SCREW M10X25 MM (8.8) |
|
20 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
21 |
16607624 |
SCREW M10X25 |
|
22 |
17288981 |
O-RING Ø29,74 MM SP=3,53 MM |
