8291SRM75.32A007
3020.032/02 OIL FILTERS
| Item | Part number | Description |
|---|---|---|
| 1 | 8009716 | VALVE |
| 2 | 8009717 | HANDLE BALL |
| 3 | 8009718 | SUPPORT |
| 4 | 8009719 | ROD |
| 5 | 8009742 | SPACING BAR |
| 6 | 8009720 | LEVER |
| 7 | 17236510 | PIN Ø4X20 MM |
| 8 | 8009722 | RETAINER |
| 9 | 8009723 | RETAINER |
| 10 | 8009724 | PLUG |
| 11 | 8009725 | BALL |
| 12 | 8009726 | SPRING |
| 13 | 8009727 | SPRING |
| 14 | 17289481 | O-RING Ø37,69 MM SP=3,53 MM |
| 15 | 16873076 | CIRCLIP |
| 16 | 16866276 | CIRCLIP Ø22X1,2 MM |
| 17 | 17221020 | KEY M12X110 MM |
| 18 | 16603524 | SCREW M6X12 MM (8.8) |
| 19 | 16603624 | HEXAGON BOLT M6X16 MM (8.8) |
| 20 | 17088474 | WASHER Ø6X12 MM |
