| Item |
Part number |
Description |
|
1 |
8013360 |
WATER PIPE |
|
2 |
8008755 |
FLAT ENGINE GASKET |
|
3 |
17037931 |
HEXAGON NUT M8X1,25 |
|
4 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
5 |
17764793 |
CLIP Ø32/50 MM |
|
6 |
8100546 |
RUBBER SLEEVE |
|
7 |
8013361 |
WATER PIPE |
|
8 |
8103077 |
CLIP |
|
9 |
8104316 |
WATER HOSE |
|
10 |
17764893 |
CLIP Ø40/60 MM |
|
11 |
8813238 |
WATER HOSE |
|
12 |
8114208 |
RETAINER [up to 09-93] |
|
13 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
14 |
4858606 |
GASKET Ø10X14X1 MM |
|
15 |
16992140 |
PLUG M10X1 |
|
16 |
8105276 |
PLUG M16 |
|
17 |
8105277 |
SACRIFICAL ANODE Ø14 MM |
|
18 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
19 |
8013362 |
WATER PIPE |
|
20 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
21 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
22 |
8013359 |
WATER PIPE |
|
24 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
|
25 |
8007133 |
RETAINER |
|
26 |
15540321 |
HEXAGON BOLT M12X1,25X25 MM |
|
27 |
17038221 |
HEXAGON NUT M10 |
