| Item |
Part number |
Description |
|
1 |
8017454 |
SPACING BAR ASSY |
|
2 |
8017337 |
OIL/WATER HEAT EXCHANGER ASSY |
|
3 |
17873671 |
THREADED INSERT M12X1,25 |
|
4 |
17095304 |
WASHER �12X24 MM |
|
5 |
17278981 |
O-RING �25,12 MM SP=1,78 MM |
|
6 |
4853307 |
CENTERING BUSH |
|
7 |
17282581 |
O-RING �28,24 MM SP=2,62 MM |
|
8 |
16993440 |
PLUG M22X1,5 |
|
9 |
10263460 |
WASHER �22X28X1,5 MM |
|
10 |
15540921 |
HEXAGON BOLT M12X1,25X55 MM |
|
11 |
17090174 |
SPRING WASHER �10X20 MM |
|
12 |
17282181 |
O-RING �21,8 MM SP=2,6 MM |
|
13 |
17089474 |
SPRING WASHER �8X16 MM SP=1,4 MM |
|
14 |
15970621 |
SCREW M10X1,25X22 |
|
15 |
8017308 |
RETAINER |
|
16 |
17873271 |
THREADED INSERT M8 |
|
17 |
16748424 |
STUD M10X20X20 |
|
18 |
16746524 |
STUD M8X16X16 |
