| Item |
Part number |
Description |
|
1 |
8026715 |
SPACING BAR |
|
2 |
17873271 |
THREADED INSERT M8 |
|
3 |
17873521 |
THREADED INSERT |
|
4 |
8008906 |
GASKET |
|
5 |
16729424 |
STUD M8X1,25X25 |
|
6 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
7 |
17037931 |
HEXAGON NUT M8X1,25 |
|
8 |
8005787 |
INTAKE ELBOW |
|
9 |
8005757 |
AIR HOOD |
|
10 |
17296181 |
O-RING Ø59,69X5,33 MM |
|
11 |
16992511 |
THREADED PLUG M18X1,5 |
|
12 |
4858610 |
WASHER Ø18X24 MM SP=1,5 MM |
|
13 |
8006782 |
RETAINER |
|
14 |
4865230 |
TURBOCHARGER HOSE |
|
15 |
8007611 |
CLIP |
|
16 |
8013472 |
EXHAUST ELBOW |
|
17 |
8024880 |
EXHAUST BELLOWS |
|
18 |
8111833 |
GASKET |
|
19 |
8009600 |
GASKET |
|
20 |
16992240 |
THREADED PLUG M12X1,5 |
|
21 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
24 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
25 |
17038121 |
HEXAGON NUT M10 |
|
26 |
16729224 |
STUD M8X16 MM |
|
27 |
16731234 |
STUD M10X1,5X25 |
|
28 |
8103591 |
FLANGE |
