8460SM22.12
0710.047 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 61318094 | INTAKE ELBOW ASSY |
| 2 | 17090174 | SPRING WASHER Ø10X20 MM |
| 3 | 15972424 | HEXAGON BOLT M10X1,25X130 MM |
| 4 | 15972124 | HEXAGON BOLT M10X115 MM |
| 5 | 11306924 | HEXAGON BOLT M10X1,25X30 MM |
| 6 | 61321089 | INTAKE ELBOW GASK. |
| 7 | 61586207 | PLATE |
| 8 | 61316833 | INTAKE ELBOW GASK. |
| 9 | 15004021 | HEXAGON BOLT M10X1,25X25 MM |
| 10 | 4871435 | PLUG |
