C10ENTC23.00A004
A08010514 PUSHER FAN - dia. 820
| Item | Part number | Description |
|---|---|---|
| 1 | 8041461 | FAN EIGHT BLADES |
| 2 | 16690625 | CYLIND-HEAD SCREW M8X25 MM |
| 3 | 8037429 | HUB |
| 4 | 16707134 | SOCKET-HEAD SCREW M8X20 MM |
| 5 | 17096824 | WASHER Ø8,40X15 MM |
