| Item |
Part number |
Description |
|
1 |
8039404 |
AIR CLEANER ASSY |
|
2 |
8039901 |
SUPPORT |
|
3 |
17291481 |
O-RING Ø101,19 MM SP=3,53 |
|
4 |
8043376 |
SUPPORT ASSY |
|
5 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
6 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
7 |
8031906 |
TIE ROD M6X1 |
|
8 |
16603525 |
SCREW M6X12 MM |
|
9 |
17088674 |
WASHER Ø6X15X1,5 MM |
|
10 |
8030569 |
HANDWHEEL M6X1 |
|
11 |
8032358 |
CLIP dia 154 |
|
12 |
8039624 |
AIR FILTER ELEMENT |
|
13 |
4633506 |
THREADED UNION M22X1,5 |
|
14 |
18088493 |
CLIP |
|
15 |
8044073 |
RUBBER SLEEVE |
|
16 |
8043388 |
SPACING BAR |
|
17 |
8043381 |
RUBBER GASKET |
|
18 |
16992611 |
THREADED PLUG M22X1,5 |
|
19 |
99489022 |
SEAL GASKET Ø22X30 MM SP=1,5 MM |
