| Item |
Part number |
Description |
|
1 |
8030540 |
AIR HOOD |
|
2 |
8030438 |
COVER |
|
3 |
98483071 |
FLAT ENGINE GASKET |
|
4 |
8030532 |
INTAKE ELBOW |
|
5 |
4800661 |
CLIP � 75 mm. |
|
6 |
17284681 |
O-RING �61,6 MM SP=2,62 MM |
|
7 |
8030546 |
AIR PIPE/DUCT |
|
8 |
8009896 |
ADAPTER |
|
9 |
17290581 |
O-RING �72,63X3,53 MM |
|
10 |
16606324 |
HEXAGON BOLT M8X60 MM |
|
11 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
12 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
13 |
17088474 |
WASHER �6X12 MM |
|
14 |
16608124 |
HEXAGON BOLT M10X1,5X50 MM |
|
15 |
17090174 |
SPRING WASHER �10X20 MM |
|
16 |
8030401 |
MARINE EXHAUST PIPE ASSY |
|
17 |
16991170 |
LOCK PLUG �36 MM |
|
18 |
16990570 |
LOCK PLUG �20 MM |
|
19 |
8030364 |
GASKET |
|
20 |
16748634 |
STUD M10X30 |
|
21 |
16629934 |
HEXAGON BOLT M12X35 MM |
|
22 |
17091174 |
SPRING WASHER �12X24 MM |
