C78ENTM50.10
5690.043/03 CABLES
| Item | Part number | Description |
|---|---|---|
| 1 | 8030938 | SUPPORT |
| 2 | 98498817 | DOWEL |
| 3 | 8030939 | SUPPORT |
| 4 | 16729624 | STUD M8X35 |
| 5 | 17037921 | HEXAGON NUT M8X1,25 |
| 6 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 7 | 16586924 | HEXAGON BOLT M8X50 MM |
| 8 | 16597224 | HEXAGON BOLT M6X18 MM |
| 9 | 17088774 | WASHER Ø6 MM |
| 10 | 17037821 | HEXAGON NUT M6X1 |
