| Item |
Part number |
Description |
|
1 |
8034708 |
AIR CLEANER ASSY |
|
2 |
17089474 |
SPRING WASHER �8X16 MM SP=1,4 MM |
|
3 |
8045573 |
FILTER SUPPORT |
|
4 |
16609924 |
HEXAGON BOLT M12X30 MM (8.8) |
|
5 |
8015315 |
PIPE SOCKET |
|
6 |
8043418 |
RETAINER |
|
7 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
8 |
17038131 |
HEXAGON NUT M10 |
|
9 |
8027294 |
CHOCKED FILTER INDIC. MECHANICAL |
|
10 |
17038425 |
HEXAGON NUT M12 (8) |
|
11 |
16607624 |
SCREW M10X25 |
|
12 |
17090274 |
WASHER �10X20 MM |
|
13 |
17091074 |
WASHER �12X24X2,8 MM |
|
14 |
16607724 |
HEXAGON BOLT M10X1,5X30 MM (8.8) |
|
15 |
17090174 |
SPRING WASHER �10X20 MM |
|
16 |
16588025 |
HEXAGON BOLT M12X30 MM |
|
17 |
8031596 |
HOOK FRONT |
|
18 |
16605424 |
SCREW M8X16 MM (8.8) |
|
19 |
16607424 |
SCREW M10X16 |
|
20 |
8043421 |
RETAINER |
|
21 |
17765992 |
HOSE CLIP DIAM=150170 MM |
|
22 |
5801591882 |
FILTER HOSE |
|
23 |
17765794 |
CLIP �130/150 MM |
|
24 |
5801541435 |
CONNECTOR SLEEVE |
|
25 |
5801583542 |
FLANGE |
|
26 |
16978124 |
HEXAGON BOLT |
|
27 |
5801588119 |
FILTER HOSE |
|
28 |
17765591 |
CLIP �110/130 MM |
|
29 |
8015133 |
PIPE SOCKET |
|
30 |
8036887 |
RUBBER SLEEVE |
|
31 |
17764594 |
HOSE CLIP |
