| Item |
Part number |
Description |
|
1 |
504026624 |
FLAT ENGINE GASKET |
|
2 |
504081905 |
INTAKE ELBOW |
|
3 |
16593024 |
HEXAGON BOLT M10X1,5X90 MM |
|
4 |
16598924 |
HEXAGON BOLT M10X110 |
|
5 |
8025135 |
AIR PIPE/DUCT |
|
6 |
98401052 |
FLAT ENGINE GASKET |
|
7 |
16586925 |
HEXAGON BOLT M8X50 MM |
|
8 |
8029990 |
VALVE |
|
9 |
504075411 |
RUBBER SLEEVE |
|
10 |
17765494 |
CLIP dia. = 100/120 |
|
11 |
4740662 |
BANJO COUPLING |
|
12 |
98474305 |
WASHER �10X17 MM SP=2,3 |
|
13 |
4864080 |
SCREW CONNECTOR M10X1,25 |
|
14 |
504076044 |
RUBBER HOSE |
|
15 |
18087692 |
CLIP �8/12 MM |
|
16 |
504070711 |
THREADED UNION M28X1,5 |
|
17 |
16571960 |
SEAL GASKET |
|
18 |
504095001 |
HOSE |
|
19 |
504075337 |
RUBBER HOSE |
|
21 |
504076043 |
INTAKE ELBOW [UP TO # 51062] |
|
22 |
504076144 |
CONNECTOR SLEEVE |
|
23 |
17765192 |
HOSE CLIP �70-90 MM |
|
24 |
504087835 |
FASTENING BRACKET |
|
25 |
16586225 |
HEXAGON BOLT M8X1,25X16 MM |
|
26 |
504087836 |
RETAINER |
|
27 |
17089574 |
WASHER �8X16 MM |
|
28 |
17044725 |
HEXAGON NUT M8 |
|
29 |
17044825 |
HEXAGON NUT M10 |
|
30 |
16673735 |
HEXAGON BOLT M8X25 MM |
|
31 |
504101880 |
INTAKE ELBOW |
