| Item |
Part number |
Description |
|
1 |
504013550 |
HEAT EXCHANGER ASSY |
|
2 |
500301692 |
OIL COOLER |
|
3 |
17283581 |
O-RING Ø44,12 MM SP=2,62 MM |
|
4 |
16673934 |
HEXAGON BOLT M8X35 MM |
|
5 |
16586924 |
HEXAGON BOLT M8X50 MM |
|
6 |
99489014 |
SEAL GASKET Ø7 MM |
|
7 |
99433799 |
THREADED PLUG M32X1,5 |
|
8 |
99433798 |
SPACING BAR Ø28 MM |
|
9 |
98498322 |
VALVE |
|
10 |
98494952 |
GASKET M35X1,5 |
|
11 |
99469897 |
TRANSMITTER |
|
12 |
98445111 |
PRESSURE SWITCH BORLETTI |
|
13 |
17278181 |
O-RING [FROM # 50368] |
|
14 |
500337199 |
O-RING [FROM # 50368] |
|
15 |
504013552 |
OIL FILTER SUPPORT [FROM # 13703] |
|
16 |
16598624 |
HEXAGON BOLT M8X1,25X140 MM |
|
17 |
504013562 |
GASKET |
|
18 |
16598224 |
HEXAGON BOLT M8X90 MM |
|
19 |
16992411 |
THREADED PLUG M16X1,5 |
|
20 |
99489019 |
WASHER Ø16X24 MM SP=1,5 MM |
|
21 |
16993711 |
THREADED PLUG M35X1,5 |
|
22 |
99469380 |
SEAL GASKET Ø35 MM |
|
23 |
16993511 |
LOCK PLUG M28X1,5 |
|
24 |
99432291 |
SEAL GASKET Ø28 MM |
|
25 |
98497873 |
FLAT ENGINE GASKET |
|
26 |
16674034 |
HEXAGON BOLT M8X40 MM |
|
27 |
500337200 |
THREADED PLUG [FROM # 50368] |
