F2BE0684B*B131
3253.012 WATER LINES
| Item | Part number | Description |
|---|---|---|
| 1 | 500313369 | WATER PIPE |
| 2 | 4864084 | BANJO BOLT M16X1,5 |
| 3 | 16511511 | SCREW CONNECTOR |
| 4 | 98474309 | WASHER Ø16X24 MM SP=1,9 MM |
| 5 | 98474311 | SEAL GASKET Ø18X26 MM |
| 6 | 99473920 | WATER PIPE |
| 7 | 41031569 | THREADED UNION M16X1,5 - M18X1,5 MM" |
| 8 | 4741574 | THREADED UNION M18X1,5 - M18X1,5 |
| 9 | 99489020 | SEAL GASKET Ø18X26 MM SP=1,5 MM |
| 10 | 99489019 | WASHER Ø16X24 MM SP=1,5 MM |
