F2BE3681B*U056
8600.310 ACCESSORIES - for mechanic.gearbox
| Item | Part number | Description |
|---|---|---|
| 1 | 8030575 | CONNECTION ASSY |
| 2 | 500363489 | WIRE CONNECTOR |
| 3 | 500363578 | COVER |
| 4 | 500363737 | RUBBER BUSH |
| 5 | 500395785 | RUBBER BUSH |
| 6 | 500363580 | TERMINAL |
| 7 | 8030193 | WIRE CONNECTOR assy 5 pin female |
| 8 | 17284681 | O-RING Ø61,6 MM SP=2,62 MM |
| 9 | 99468264 | SENSOR |
| 10 | 99430234 | PLUG COUPLING |
| 11 | 12309290 | TERMINAL |
| 12 | 4835259 | GASKET |
| 13 | 99460566 | PREFILTER ASSY |
| 14 | 500316868 | FUEL FILT.SUPPORT |
| 15 | 1908547 | FUEL FILTER ELEM. |
| 16 | 17291281 | O-RING Ø94,84 MM SP=3,53 MM |
