| Item |
Part number |
Description |
|
1 |
16588225 |
HEXAGON BOLT M12X40 MM |
|
2 |
8050744 |
WATER PIPE |
|
3 |
8050745 |
WATER PIPE |
|
4 |
8040142 |
RUBBER SLEEVE Ø45x70 MM |
|
5 |
98447313 |
WATER HOSE Ø45 MM/Ø38 MM |
|
6 |
17764892 |
PIPE CLIP Ø40-60 MM |
|
7 |
8050742 |
AIR PIPE/DUCT |
|
8 |
8050743 |
AIR PIPE/DUCT |
|
9 |
8050695 |
RUBBER SLEEVE Ø50 MM/Ø 60 MM |
|
10 |
8107383 |
RUBBER SLEEVE Ø60 MM |
|
11 |
17764991 |
CLIP Ø50/70 MM |
|
12 |
4899921 |
FLAT ENGINE GASKET |
|
13 |
16673735 |
HEXAGON BOLT M8X25 MM |
|
14 |
8049995 |
WATER RADIATOR ASSY |
|
15 |
16587525 |
HEXAGON BOLT M10X45 MM |
|
16 |
8050757 |
REAR ENG. MOUNT |
|
17 |
16678135 |
HEXAGON BOLT M12X45 MM |
|
18 |
16588025 |
HEXAGON BOLT M12X30 MM |
|
19 |
8050740 |
RETAINER |
|
20 |
8050741 |
TIE ROD |
|
21 |
741569 |
RUBBER LUG |
|
22 |
741570 |
WASHER Ø10X17 MM SP=2,3 |
|
23 |
741571 |
SPACING BAR Ø10X17 MM SP=2,3 |
|
24 |
11343721 |
HEXAGON BOLT M10X65 MM |
|
25 |
17044921 |
HEXAGON NUT M12 |
|
26 |
8050719 |
HOOK |
|
27 |
8108634 |
SPACING BAR |
|
28 |
16600224 |
HEXAGON BOLT M8X1,25X18 MM |
|
29 |
8051981 |
SUPPORT |
|
30 |
8050694 |
RUBBER SLEEVE Ø40 MM/Ø33 MM |
