Catalogue Menu
F4AE0481A*C103
1405.016 HYDRAUL. ACCUMULATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 4898637 | HYDRAULIC CYLINDER |
| 2 | 4893833 | THREADED UNION |
| 3 | 4858608 | SEAL GASKET dia.14x19,5x1,5 |
| 4 | 4898653 | VALVE |
| 5 | 4897501 | SENSOR ASSY [UP TO: 189668] |
| 6 | 500372236 | WASHER |
| 7 | 4898654 | VALVE |
| 8 | 4897061 | FUEL LINE |
| 9 | 4897062 | FUEL LINE |
| 10 | 4897063 | FUEL LINE ASSY |
| 11 | 4897270 | FASTENING BRACKET |
| 12 | 4897272 | FASTENING BRACKET |
| 13 | 16693624 | SOCKET-HEAD SCREW |
| 14 | 4898270 | SCREW |
| 15 | 4897411 | WASHER |
| 16 | 4899872 | FASTENING BRACKET Ø6 MM |
| 17 | 4899888 | HEXAGON BOLT M8X105 MM |
